SR-01

SR-01 Obstetric aid table

Obstetric table SR-01 is ideal for equipping perinatal centers, maternity hospitals and departments. The table is designed taking into account the latest achievements in obstetrics and gynecology and meets the high standards of modern medical equipment.

Required positioning of the woman in labor is carried out using a remote control. Head section adjustments are carried out with the help of a gas spring.

The ergonomic design of the table is convenient for the medical staff and maximum comfortable for the woman in labor. Thanks to its functionality, SR-01 obstetric table can be used as a table for operations requiring a spinal positioning, as well as a regular gynecological chair.

Features:

  • Metal elements of the accessories are made of stainless steel, surfaces are matte, resistant to non-chlorine disinfectants
  • Removable mattresses made from polyurethane
  • Feet rests and leg holders are adjustable in angle and height by clamps
  • Removable patient handles
  • Withdrawable table for a newborn is extended and fixed steplessly with the help of a gas spring
  • Withdrawable container (volume 13L) is made of stainless steel, can be freely removed from the holder for disinfection
  • For ease of movement, the base has Ø100 mm swivel castors with a central brake

Adjustments:

  • Lifting/lowering of the table – electric drive
  • Backrest tilt – electric drive
  • Seat tilt – electric drive
  • Zero position - electric drive
  • Head section tilts – gas spring

Our recommendations:

Warranty 24 month.

Attention!
The information presented on the website has an advertising nature. For up-to-date information on product design and its technical characteristics, please contact our sales department!

  • Table height (horizontal sections positioning)
  • - min position620 mm
  • - max position870 mm
  • Table stroke250 mm
  • Table top length with drawn out and turned down table for a newborn1850 mm
  • Table top length with drawn out and turned up table for a newborn1920 mm
  • Table width655 mm
  • Table width (incl. side rails)710 mm
  • Back section tilt (up)55º
  • Head section tilt (up) related to the back section30º
  • Longitudinal tilt (up/down)5º/20º
  • Withdrawable table pads size490*470 mm
  • Table height adjustment range100 mm
  • Safe working load200 kg
  • Weight190 kg
  • Power supply voltage 230V 50Hz
  • Batteries charging time5-6 h
