OK-BETA is the most popular and sought-after model in the MEDIN operating table range. OK-BETA is general surgery table with electomechanical adjustment. Combined with sets of additional accessories allows full range of surgery operations.

OK-BETA is an universal, easy to operate general surgery table. It can be used in medical centres and hospitals, both for general surgery operations and for specialised operations with the use of additional sets of accessories produced by the company.

The main positions of the table are controlled by means of a hand wired console. The integrated wheels facilitate moving the table inside the operating room.

Features:

All open metal surfaces and additional accessories are made of stainless steel
Table base is protected by extra proof composite base cover and column protected by stainless steel casing
Mobile base with castors and central lock
Table top return to the ZERO POSITION
Built-In rechargeable batteries
Removable, antistatic, seamless, molded polyurethane foam mattresses made with antibacterial ASP technology
Two modifications of the table panel - 5 sections or 6 sections
X-ray translucent table top
C-Arm compatible
Longitudinal shift (optional) 320 mm
Dorsal section bending (optional) 105 mm
Input of the X-ray film cartridge from head or leg sections
Head and leg sections are adjustable
Extensible supports to fix the table
Compatible with wide variety of additional accessories

Adjustments:

Lifting/lowering of the table top - electromechanical
Trendelenburg/reverse Trendelenburg - electromechanical
Lateral tilt - electromechanical
Return table top to zero position - electromechanical
Dorsal section tilt - gas springs
Longitudinal shift (optional) - mechanical
Dorsal section bending (optional) - mechanical
Central brakes control - foot pedal
Leg and head sections - gas springs

Modifications:

ОК-BETA - basic configuration
ОК-BETA-01 - dorsal section bending
ОК-BETA-02 - table top longitudinal shift
ОК-BETA-03 - dorsal section bending and table top longitudinal shift

Used with the following KPP sets:

01	02	03	04	05	06	07	08
09	10	11	12	13	14	15	16
17	18			21	22
25	26	27	28	29	30	31	32
33	34	35	36	37	38	39	40
41	42	43

The table is equipped with the set of accessories for general surgery (KPP-01).

Recommendation:

To increase work efficiency of the medical staff, we recommend using a unique solution for organizing the workplace of a nurse: a functional medical trolley TM-1.

Warranty 24 months!

Attention!
The information presented on the website has an advertising nature. For up-to-date information on product design and its technical characteristics, please contact our sales department!

Technical parameters	ОК-BЕТА	ОК-BЕТА-01	ОК-BЕТА-02	ОК-BЕТА-03
Min. table top height (pads thickness is not included)	660 mm	660 mm	660 mm	660 mm
Max. table top height (pads thickness is not included)	1080 mm	1080 mm	1080 mm	1080 mm
Table top length	2100 mm	2100 mm	2100 mm	2100 mm
Table top length (without head and leg sections)	1100 mm	1100 mm	1100 mm	1100 mm
Table top width	500 mm	500 mm	500 mm	500 mm
Table top width over the side rail	550 mm	550 mm	550 mm	550 mm
Table base height	140 mm	140 mm	140 mm	140 mm
Table base length	1050 mm	1050 mm	1050 mm	1050 mm
Table base width	560 mm	560 mm	560 mm	560 mm
Table base width (in the area of the column)	435 mm	435 mm	435 mm	435 mm
Table top longitudinal tilt (Trendelenburg/reverse Trendelenburg position)	30º/30º	30º/30º	30º/30º	30º/30º
Dorsal section tilt (up/down)	75º/45°	75º/45°	75º/45°	75º/45°
Head section tilt (up/down)	30º/35°	30º/35°	30º/35°	30º/35°
Leg section tilt (up/down)	30º/90°	30º/90°	30º/90°	30º/90°
Table top lateral tilt (right/left)	20º/20º	20º/20º	20º/20º	20º/20º
Table top longitudinal shift	no	no	320 mm	320 mm
Max. head section shift	50 mm	50 mm	50 mm	50 mm
Pads lifting (provided dorsal section bending)	no	105 mm	no	105 mm
Safe working load	220 kg	220 kg	220 kg	220 kg
Safe working load (with functions limitation)	270 kg	270 kg	270 kg	270 kg
Table weight (without removable accessories set)	220 kg	220 kg	220 kg	220 kg
Maximum table load	320 kg	320 kg	320 kg	320 kg
