ОК-ТЕТА-PLUS general surgery table

Description Technical parameters Documents to download Related products

OK-TETA-PLUS general surgery table

Electromechanical table OK-TETA-PLUS is a universal multifunctional operating table for the whole range of surgical operations (with sets of removable accessories).
OK-TETA-PLUS is mobile and easily adjustable table due to high quality electromechanical drives. The multifunctional table fulfils various surgical requirements: height adjustment, lateral tilt, panel and section tilt, longitudinal shift, possibility to use with C-arm. OK-TETA-PLUS combines high performance, surgical functionality and safety for medical team and patients.

Features:

All open metal surfaces and additional accessories are made of stainless steel
Low column base increases the space for X-Ray system operation with C-arm
Ergonomically for surgeon’s legs
Electric power via battery or via power supply network (230 V)
Head and leg sections quick fixation
Interchangeable head and leg sections
Extended up to 540 mm table top width
Increased on 25% zone of radiolucency (compared to OK-TETA and OK-BETA operating tables)
Viscoelastic mattress with memory effect
М1, М2 positions are programmed by the user
Cordless remote control (accessory)
In-built system of safe table management

Adjustments:

Lifting/lowering of the table top - electromechanical
Trendelenburg/reverse Trendelenburg - electromechanical
Lateral tilt - electromechanical
Longitudinal shift - electromechanical
Dorsal section tilt - electromechanical
Return table top to zero position - electromechanical
Leg and head sections - gas springs
Dorsal section bending - mechanical

Modifications:

ОК-ТЕТА-PLUS - dorsal section bending
ОК-ТЕТА-PLUS-01 - with kidney bridge

Used with the following KPP sets:

01	02	03	04	05	06	07	08
09	10	11	12	13		15	16
17	18
	26	27	28	29	30	31	32
33	34	35	36	37	38	39	40
41	42	43

The operating table is equipped with the set of accessories for general surgery (KPP-01).

Additional accessories:

Wireless remote control
Pedal control panel

Warranty 24 months.

Attention!
The information presented on the website has an advertising nature. For up-to-date information on product design and its technical characteristics, please contact our sales department!

Technical parameters	ОК-TETA-PLUS	ОК-ТЕТА-PLUS-01
Min. table top height (pads thickness is not included), not more than	630 mm	630 mm
Max. table top height (pads thickness is not included), not less than	1050 mm	1050 mm
Table top length, not less than	2150 mm	2150 mm
Table top length (without head and leg sections), not less than	1150 mm	1150 mm
Table top width, not less than	540 mm	540 mm
Table top width (incl. side rails), not less than	590 mm	590 mm
Table base height	140 mm	140 mm
Table base length	1050 mm	1050 mm
Table base width	560 mm	560 mm
Table base width at the column area, not more than	435 mm	435 mm
Table top longitudinal tilt (Trendelenburg/ reverse Trendelenburg position), not less than	30º/30º	30º/30º
Dorsal section tilt (up/down), not less than	70º/40°	70º/40°
Head section tilt (up/down), not less than	30º/35°	30º/35°
Leg section tilt (up/down), not less than	30º/90°	30º/90°
Table top lateral tilt (right/left), not less than	20º/20º	20º/20º
Table top longitudinal shift, not less than	320 mm	320 mm
Lifting height of the kidney bridge, not less than	no	120 mm
Pads lifting (provided dorsal section bending), not less than	105 mm	no
Table safe working load	220 kg	220 kg
Table safe working load (with functions limitation)	270 kg	270 kg
Table weight (without removable accessories), not more than	260 kg	260 kg
Maximum table load	320 kg	320 kg
